وحده إمداد الطاقة غير المنقطعة من شنايدر الكتريك APC Smart-UPS On-Line, 3kVA, Tower, 230V, 8x C13+2x C19 IEC outlets, SmartSlot, Extended runtime, W/O rail kit

Model: SRT3000XLI

تحميل ملف المواصفات

تمت الاضافة للقائمة

SKU SRT3000XLI Categories APC Smart On-Line UPS, APC Smart Online Tower UPS, APC Smart UPS Tags APC Smart-UPS, Online UPS, Optimum UPS, Smart UPS, SRT3000XLI

Overview
Presentation	High density, double-conversion on-line power protection with scalable runtime.
Lead time	Usually in Stock

Main
Main input voltage	230 V
Other input voltage	220 V 240 V
Main output voltage	230 V
Other output voltage	220 V 240 V
Rated power in W	2700 W
Rated power in VA	3000 VA
Plug standard	BS1363A British IEC 60320 C20 Schuko CEE 7 / EU1-16P
Output Connection type	8 IEC 60320 C13 2 IEC Jumpers 2 IEC 60320 C19
Cable length	2.44 m
Number of cables	3
Battery type	Lead-acid battery
Provided equipment	CD with software Country-specific detachable power cord Documentation CD Installation guide Removable support feet USB cable Warranty card

General
Product web sub-family	High density
Number of power module filled slots	0
Number of power module free slots	0
Redundant	No

Physical
Color	Black
Height	43.2 cm
Width	8.5 cm
Depth	63.5 cm
Net weight	31.3 kg
Mounting location	Front
Mounting preference	Lower
Mounting mode	Rack-mounted with kit
Two post mountable	0
USB compatible	Yes
Mounting position	Vertical

Input
Network frequency	40…70 Hz auto-sensing
Input voltage limits	100…275 V adjustable (half load)

Output
Maximum configurable power in W	2700 W
Harmonic distortion	Less than 2 %
Output frequency	50/60 Hz +/- 3 Hz sync to mains
Crest factor	3 : 1
UPS type	Double conversion online
Wave type	Sine wave
Bypass type	Internal bypass (automatic and manual)
Maximum configurable power in VA	3000 VA

Conformance
Product certifications	CE EAC IRAM RCM VDE
Marking	CE Mark
Standards	EN/IEC 62040-1:2019/A11:2021 EN/IEC 62040-2:2006/AC:2006 EN/IEC 62040-2:2018

Environmental
Ambient air temperature for operation	0…40 °C
Relative Humidity	0…95 % non-condensing
Operating altitude	0…10000 ft
Ambient air temperature for storage	-15…45 °C
Storage Relative Humidity	0…95 % non-condensing
Storage altitude	0.00…15240.00 m
Acoustic level	55 dBA
Heat dissipation	703 Btu/h
IP degree of protection	IP20

Batteries & Runtime
Run Time	View Run Time Graph
Efficiency	View Efficiency Graph
Battery recharge time	3 h
Number of battery replacement quantity	1
Additional information	Configurable for 220 : 230 or 240 nominal output voltage
Battery voltage	96 V
Battery charger power	168 W rated
Battery power in VAH	505 VAh runtime
Battery life	3…5 year(s)
Replacement battery	APCRBC152
Battery option	SRT96BP 1 1515 VAh SRT96BP 2 2525 VAh SRT96BP 3 3535 VAh SRT96BP 4 4545 VAh SRT96BP 5 5555 VAh SRT96BP 6 6565 VAh SRT96BP 8 8585 VAh SRT96BP 10 10605 VAh
Extended runtime	1

Communications & Management
Free slots	1
Control panel	Multifunction LCD status and control console
Alarm	Audible and visible alarms prioritized by severity
Emergency power off	Yes

Surge Protection and Filtering
Surge energy rate	340 J

Packing Units
Unit Type of Package 1	PCE
Package 1 Length	59.9 cm
Number of Units in Package 1	1
Number of Units in Package 3	6
Package 1 Width	87.1 cm
Package 1 Height	24.6 cm
Package 1 Width	61 cm
Package 1 Weight	36.74 kg

Contractual warranty
Warranty	3 years repair or replace (excluding battery) and 2 years for battery
