جهاز الإمداد غير المنقطع للطاقة Easy UPS On-Line SRVS 3000VA RM 230V with Extended Runtime Battery Pack, Rail Kit من شنايدر الكتريك


Model: SRVS3KRILRK

تحميل ملف المواصفات

نظرة عامة
تقديم وحدة Online UPS عالية الجودة ومزدوجة التبديل مصممة لتلبية احتياجات حماية الطاقة الأساسية حتى في أكثر ظروف الطاقة غير المستقرة.
التوافر Usually in Stock



Main
Main input voltage 230 V
Other input voltage 220 V

240 V

Main output voltage 230 V
Other output voltage 220 V

240 V

Rated power in W 2400 W
Rated power in VA 3000 VA
Plug standard IEC 60320 C20
nb of power socket outlets 6 IEC 60320 C13

1 IEC 60320 C19

Number of rack unit 4U
Number of cables 1
Provided equipment CD with software

User manual

USB cable



General
Number of power module filled slots 0
Number of power module free slots 0
Redundant No



Physical
Height 17.2 cm
Width 43.7 cm
Depth 63.2 cm
Net weight 52 kg
Mounting location Front
Mounting preference Lower
Mounting mode Rack-mounted
USB compatible No
Mounting position Horizontal



Input
Input voltage limits 110…285 V half load

160…280 V full load

Input protection type Circuit breaker and fuse
Network frequency 40…70 Hz auto sensing



Output
Maximum Configurable Power in VA 3000 VC
Maximum configurable power in W 2400 W
Output frequency 50/60 Hz +/- 3 Hz sync to mains
UPS type Double conversion online
Wave type Sine wave
Bypass type Internal bypass (automatic and manual)
Crest factor 3 : 1



Conformance
Product certifications CE





Environmental
Ambient air temperature for operation 0…40 °C
Relative humidity 0…95 % non-condensing
Operating altitude 0…3000 m
Ambient air temperature for storage -20…50 °C
Storage Relative Humidity non-condensing 0…95 %
Storage altitude 0…15000 m
Acoustic level 50 dBA



Batteries & Runtime
Efficiency View Efficiency Graph
Battery type Lead-acid battery
Battery voltage 72 V
Number of batteries filled slots 0
Number of battery free slots 0
Battery recharge time 4 h
Battery life 3…5 year(s)
Battery charger power 234 W rated
Battery option SRVS72RLBP-9A 1 1878 VAh

SRVS72RLBP-9A 2 2817 VAh

SRVS72RLBP-9A 3 3756 VAh

SRVS72RLBP-9A 4 4695 VAh



Communications & Management
Alarm Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Control panel Multifunction LCD status and control console



Surge Protection and Filtering
Surge energy rate 600 J



Packing Units
Unit Type of Package 1 PCE
Number of Units in Package 1 3
Package 1 Weight 66.8 kg
Package 1 Height 48 cm
Package 1 width 60 cm
Package 1 Length 80 cm



Contractual warranty
Warranty 2 years repair or replace
